From wearables to smart home devices — we build the PCBs and PCBAs inside consumer products. Fast prototyping, competitive pricing, and the quality your customers expect.
If your product ends up in a consumer's hands, we have built boards like yours before.
Ultra-compact PCBAs for wearable devices. Flexible and rigid-flex boards, BLE and ANT+ communication modules, heart rate sensor interfaces, and low-power MCU boards for wrist-worn devices.
Wi-Fi and Zigbee-enabled smart home device PCBAs, voice assistant mainboards, smart display controller boards, and home automation hub PCBAs with multi-protocol wireless support.
TWS earbud PCBAs, active noise cancellation boards, Bluetooth audio codec modules, charging case controller PCBAs, and high-fidelity DAC/amplifier boards for premium audio products.
Game controller PCBAs, mechanical keyboard mainboards, gaming mouse sensor boards, RGB LED controller modules, and USB hub PCBAs for gaming peripherals and accessories.
Image sensor interface PCBAs, camera module boards, gimbal controller PCBAs, video encoder boards, and compact flight controller modules for consumer drones and action cameras.
Power bank controller PCBAs, Qi wireless charging transmitter and receiver boards, USB-C PD controller modules, and fast-charge adapter PCBAs for consumer power products.
24-hour PCB turnaround and 3-5 day PCBA prototype. Send us your Gerber files and BOM today — your boards ship this week. No waiting weeks for a first sample when your product launch timeline is tight.
We source all components, fabricate the PCB, assemble, test, and ship. No need to manage a PCB factory, a component distributor, and an assembly house separately. One quote, one order, one delivery.
Start with 1 prototype. Scale to 10,000 units when your product launches. Same factory, same quality system, same contact person. No re-qualification, no tooling fees, no minimum order at any stage.
Consumer products are getting smaller every year. We place 01005 components, 0.4 mm BGA pitch, and build HDI PCBs with microvias for the compact form factors that modern consumer electronics demand.
Wearables, earbuds, and compact devices often need flexible or rigid-flex PCBs to fit into curved or irregular enclosures. We fabricate flex and rigid-flex boards and assemble them with the same precision as rigid PCBs.
ISO 9001 certified, IPC-A-610 Class 2 standard. Full AOI and X-Ray inspection on every order. Consumer electronics needs consistent quality at volume — we deliver both without the premium pricing of boutique assemblers.
PCB Fabrication
| Parameter | Specification |
|---|---|
| Layer Count | 1 to 40 layers; HDI available |
| Material | FR4, Flex PI, Rigid-Flex, Rogers |
| Min Trace / Space | 3/3 mil standard; 2/2 mil HDI |
| Min Hole Size | 0.1 mm laser (microvia); 0.2 mm mechanical |
| Board Thickness | 0.4 mm to 6.0 mm |
| Surface Finish | ENIG, OSP, ENEPIG, Immersion Ag/Sn |
| Impedance Control | +/-5% standard; +/-3% precision |
| Prototype Lead Time | 24 hours |
PCBA Assembly
| Parameter | Specification |
|---|---|
| Assembly Type | SMT, through-hole, mixed, flex assembly |
| Min Component | 01005 imperial; 0201 metric |
| Min BGA Pitch | 0.4 mm; CSP and LGA supported |
| Placement Accuracy | +/-0.025 mm (Cpk ≥ 1.67) |
| Solder | Lead-free SAC305 (RoHS compliant) |
| Reflow | 8-zone nitrogen atmosphere oven |
| Inspection | SPI, AOI, 2D/3D X-Ray, ICT, flying probe |
| Quality Standard | IPC-A-610 Class 2 |
